North Star Sensors Datasheets

Leadless NTC Thermistors:

A2 Series Leadless Gold Wire Bondable NTC Thermistor
A1 Series Leadless NTC Thermistor

Leaded NTC Thermistors:

3XT Micro NTC Thermistor - 38 AWG insulated leads, 0.023” max bead diameter
4XT Mini NTC Thermistor - 38 AWG insulated leads, 0.037” max bead diameter
5XT Mini NTC Thermistor - 32 AWG insulated leads, 0.037” max bead diameter

1AE NTC Thermistor - 30 AWG bare tin-plated copper leads, 0.095” max bead diameter
1BE NTC Thermistor - 28 AWG bare tin-plated copper leads, 0.095” max bead diameter
1CE NTC Thermistor - 32 AWG bare tin-plated copper leads, 0.095” max bead diameter
1DE NTC Thermistor - 32 AWG bare tin-plated Alloy 180 leads, 0.095” max bead diameter
1EE NTC Thermistor - 30 AWG bare tin-plated nickel leads, 0.095” max bead diameter
1FE NTC Thermistor - 32 AWG bare tin-plated Alloy 180 leads, 0.075” max bead diameter
1GE NTC Thermistor - 30 AWG bare tin-plated Alloy 52 leads, 0.095” max bead diameter

2AE NTC Thermistor - 30 AWG solid silver-plated copper, Teflon-insulated leads, 3" L
2BE NTC Thermistor - 30 AWG solid silver-plated copper, Kynar-insulated leads, 3" L
2DE NTC Thermistor - 28 AWG solid silver-plated copper, twisted-pair Kynar-insulated leads, 3" L
2EE NTC Thermistor - 28 AWG solid silver-plated copper, twisted-pair Kynar-insulated leads, 6" L
2FE NTC Thermistor - 28 AWG solid silver-plated copper, Kynar-insulated leads, 3" L
2GE NTC Thermistor - 28 AWG solid silver-plated copper, Kynar-insulated leads, 6" L
2HE NTC Thermistor - 30 AWG solid silver-plated copper, Kynar-insulated leads, 6" L

Thermistor Probes:

MP01 NTC Thermistor Micro Probe
SP01 NTC Thermistor Surface Probe
